Aiming Laser, your precision laser solution provider!
 |
| Place of Origin: | CHINA |
| Brand Name: | AIMLASER, ELITELASER |
| Certification: | FDA |
| Model Number: | Green Laser Module |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | FOB Xi'an China |
| Packaging Details: | Anti-Static Bag or PE Bag |
| Delivery Time: | 2-4 Weeks |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 20,000pcs/Month |
| High Light: | laser module,blue laser module |
||
|---|---|---|---|
Wide Temperature Operating GLM is our great solution for the narrow operating temperature range of the normal green laser module. Its high brightness, wide operating temperature range are very fit for the use in the wild environments and many tough outdoor conditions, such as in hot and cold places, deserts or highly humid places.
Key Features:
1.Wide Temp. Operating
2.Low Power Consumption
3.Small Divergence
4.High Reliability
5.APC Control
6.Mini Size
Application:
Laser Alignment
Laser Sight
>Laser Positioning
Surveying Instrument
Medical Instrument
Military Equipment
|
Specifications |
GLM-001 |
GLM-005 |
GLM-010 |
GLM-020 |
|
Optical Output Power(CW) |
1mW |
5mW |
10mW |
20mW |
|
Wavelength |
532nm |
|||
|
Beam Divergence |
1.5mard,0.6mard,0.4mard,0.2mard |
|||
|
Power Stability |
>90% |
|||
|
Operating Temperature |
-10~50℃,0~45℃ |
|||
|
Housing Dimension |
7x25mm, 10x22mm, 10x35mm, 10x42mm, 10x55mm, |
|||
|
12x22mm, 12x35mm, 12x42mm, 12x55mm, |
||||
DPSS Green & Blue Laser Module (473nm&532nm)
Specification:
| Power Output |
30mW |
50mW |
80mW |
100mW |
150mW |
|
|
Wavelength |
473nm,532nm |
|||||
|
Beam Shape |
TEMoo |
|||||
|
Beam Diameter |
1.0±0.2mm |
|||||
|
Beam Divergence |
<1.0mard |
|||||
|
Power stability by Vop |
>80% |
|||||
|
Power Stability by Top |
>90% |
|||||
|
Operating Current |
<380mA |
<2000mA |
||||
|
Operating Temp |
-10℃～+50℃ |
-0℃～+50℃ |
||||
|
Storage Temp |
-20℃～+70℃ |
|||||
|
Lifetime |
||||||
