Elite Optoelectronics 520nm 5mW Green Laser Module Factory Class IIIa Green Laser with FDA

Elite Optoelectronics 520nm 5mW Green Laser Module Factory, Class IIIa Green Laser with FDA

1. Descriptions:

The EL52D20IG9 is a green laser module subassembly with collimated beam. The maximum laser output
power is 5.0mW at 525nm.

2. Features:

• Wavelength: 520±5nm
• Optical output power: ≤5.0mW
• Low operating current: <140mA
• Low operating voltage: 3.0VDC
• Class IIIa laser, CDRH/ROHS compatible
• Static, Surge, and Reverse Polarity Protected
• Circuit control: Auto constant current (ACC)
• Operating Temperature: -10 to 50°C

3. Optical and Electrical Characteristics:

• Wavelength: 520±5nm
• Output Power: ≤5.0mw
• Laser Modes: CW
• Output Aperture: Dia 3.0mm
• Beam Size: <2x4mm (@6 feet) and <3x6mm (@12 feet)
• Divergence: 0.4mrad
• Optics: Glass lens
• Operating Current: <180mA
• Operating Voltage: 3.0VDC
• CDRH Class: Class IIIa
• MTTF: 8000Hrs.

4. Mechanical Characteristics:

• Dimensions: 10x30mm (APC Outside)
• Case Materia: Brass

5. ​Why Choose us?

• 13 years rich industry experience since 2003
• SGS TUV assessed supplier
• Have FDA, ISO9001:2008, IEC certificates
• Cooperation with Top 500 Global Companies like GE, Corning etc.

6. Delivery & Payment Information:

• Shipment Term: FOB Xi’an, China.
• Payment Terms: T/T, Western Union, Paypal
• Shipping Method: DHL/UPS/TNT/FedEx Air-Express

7. Elite Factory Over view:

Established in 2003, Elite Optoelectronics Co., LTD. covering an area of 2,200 sq.m with 120 staffs, is a professional designer and manufacturer of laser diode modules, Bios lasers, fiber coupled laser modules, DPSS laser modules, laser line projector, laser bore sighters, laser sights etc.
